Dorégrill
Mag Gas & Electric
Spit-Roast Rotisserie
Traditional Rotisserie Cooking
for maximum performance
When tradition and technical perfection come together: the MAG spit-roast rotisserie oven combines classic roasting with maximum efficiency. Specially designed for continuous use by specialist meat roasters, in supermarkets or for holiday locations, this combines power, speed and a mouth-watering wall of spit-roasting meat.
Trusted By the Biggest Names in Foodservice
*Available in Both Gas & Electric Models*
Technical Characteristics
| MODEL | LENGTH | HEIGHT (NO TROLLEY) | HEIGHT (WITH TROLLEY/CABINET) | DEPTH | NUMBER OF SPITS | CAPACITY PER HOUR (DEPENDENT ON WEIGHT) |
| MAG 4 | 1480 MM | 1130 MM | 1970 MM | 690 MM | 4 | 24/28 CHICKENS |
| MAG 6 | 1480 MM | 1490 MM | 1970 MM | 690 MM | 6 | 36/42 CHICKENS |
| MAG 6 (SHORT) | 1110 MM | 1490 MM | 1970 MM | 690 MM | 6 | 24/30 CHICKENS |
| MAG 8 | 1480 MM | 1850 MM | 1970 MM | 690 MM | 8 | 48/56 CHICKENS |
| MAG 8 (SHORT | 1110 MM | 1850 MM | 1970 MM | 690 MM | 8 | 32/40 CHICKENS |
| MODEL | POWER | GAS NHO* | GAS PROPANE G31 | NAT. GAS 20MB |
| MAG 4 | 20 kW | 28 kW | 2 kg/h | 2.68 m3/h |
| MAG 6 | 29.5 kW | 42 kW | 3 kg/h | 4.02 m3/h |
| MAG 6 (SHORT) | / | 24.6 kW | 2.8 kg/h | 3.80 m3/h |
| MAG 8 | 40.3 kW | 56 kW | 4 kg/h | 5.36 m3/h |
| MAG 8 (SHORT | / | 32.8 kW | 3.7 kg/h | 5.00 m3/h |
key features
Performance:
The spits are inserted and guided directly into the independent motors (adjustable depth), radiating cooking with gas burners or reinforced “incoloy” infrared elements, and excellent value for money.
Safety:
Heat protection with tempered glass (4 for the MAG 8), twin safety on the heating elements (gas series) and hinges connected to an “open window” blocking system. Comes with a cable tidy, too.
Capacity:
24 to 56 chickens, depending on the model.
Elegance:
Available in vitrified enamel or stainless steel, with powerful lighting (2 quartz lamps) protected by waterproof vitro-ceramic screens, laser-cut back-lit “Rôtisserie” logo and silver-plated tap fittings with the DORÉGRILL logo. OPTIONAL: “Luxury” finish (brass)
Easy to clean:
The interior can be fully dismantled, and the inside corners are rounded. The interior is 100% enameled.
Ergonomics:
The Simplifil® (Dorégrill patented) spits make handling and cleaning safe and easy. Temperature regulation from 20-300 °C by thermostat (electrical series), independent burner regulation (gas series), keep-warm mode available by adjusting the oven cool-down speed.
Energy:
Available in two versions: gas (220 V mono – Propane/Nat. Gas) and electric (380 V + N + E – optional 220 V three-phase). Major gas savings, thanks to the new regulation system and more efficient new radiating elements.
